1.2 Ton Mini Excavator
1.2-ton excavator: Compact body, powerful energy
In various engineering scenarios, a flexible and efficient small excavator often plays a significant role. Our 1.2-ton mini excavator is precisely such an outstanding device that combines numerous advantages, bringing a brand-new experience to your engineering operations.
✅Flexible body, smooth movement
✅High-efficiency power and stable output
Flexible body, smooth movement
The entire excavator weighs only 1210kg, with a body width as narrow as 1040mm and a height of 2340mm. Such a compact size enables it to easily move through narrow Spaces. Whether it is the demolition work of interior decoration or the operation in limited Spaces such as orchards and vegetable greenhouses, it can move freely without being restricted by the site and easily reach corners that traditional large-scale machinery cannot reach, greatly improving work efficiency.
High-efficiency power and stable output
This mini excavator is equipped with a Yanmar engine and can output 10 at a rated speed of 2200r/min. With a rated power of 3kw, the maximum torque can reach 47.6N.M/1600 r/min. Stable power output ensures that the excavator can easily handle various working conditions during operations such as excavation and crushing. Even when facing hard soil or stones, our excavator can complete tasks effortlessly. Meanwhile, its outstanding fuel economy enables you to enjoy the pleasure of efficient operation while reducing operating costs.
| Model | CT12B4/B | Model | CT12B4/B |
| Operating weight | 1.2 | G-Tail swing radius (mm) | 806 |
| Bucket capacity | 0.03 | H-Track ground length(mm) | 972 |
| Engine model | YANMAR 3TNV74F YANMAR 3TNV70 | J-Track length (mm) | 1296 |
| Rated power (kw/r/min) | 11.2/2400 10.3/2200 | K-Track gauge (mm) | 670（870） |
| Maximum torque （N*m） | 47.6/1600 48.5/1800 | L-Track width (mm) | 850-1050 |
| Engine displacement（L） | 0.854 0.993 | M-Track shoe width (mm) | 180 |
| Max.flow (L/min) | 17.6/19.2 | N-Turntable width (mm) | 850 |
| Working pressure (Mpa) | 17 | O-Max. digging height (mm) | 3018 |
| Fuel tank capacity (L) | 15 | P-Max. dumping height (mm) | 2039 |
| Hydraulic oil tank capacity (L) | 13 | Q-Max. digging depth (mm) | 1809 |
| Travel speed (km/h) | 1.5 | R-Max. vertical wall digging depth (mm) | 1593 |
| Swing speed (r/min) | 10.5 | T-Max. digging reach (mm) | 3439 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3390 |
| Arm digging force | 6 | V-Min. swing radius (mm) | 1591 |
| Bucket digging force (KN) | 10 | X-Distance between center of rotation and tail length (mm) | 806 |
| Average grounding pressure (Kpa) | 33 | Z-Height of counterweight (mm) | 470 |
| A-Overall length (mm) | 3053 | A1-Ground length (in transportion)(mm) | 1560 |
| B-Overall width (mm) | 850/1050 | Arm length (mm) | 890 |
| C-Overall height (to top of boom)(mm) | 1035 | Boom length (mm) | 1500 |
| D-Overall height (to top of cab)(mm) | 2458 | Deflection angle left°/right° | 50°/70° |
| E-Counterweight ground clearance(mm) | 404 | Maximum dozing height/depth (mm) | 195/195 |
| F-Min. ground clearance (mm) | 120 | Dozer size width/height（mm） | 226/850(1050) |
Excavator packaging and shipment
Relying on a professional loading, unloading and logistics team, we ensure that excavators are delivered to global customers in a safe and efficient manner. We offer diversified transportation options such as standard container transportation, bulk transportation, and railway transportation.
Choose our advantages
As a manufacturer, Carter not only focuses on creating high-quality, high-performance and price-competitive products, but also attaches great importance to achieving prompt delivery and all-weather after-sales support.
Enterprise Profile
Shandong Caterpillar Heavy Industry Co., Ltd. was established in 2004 and is one of the early enterprises in China to engage in the production of excavators. The company belongs to Huasheng Zhongtian Machinery Group - a large-scale machinery group founded in 1951, with over 70 years of profound accumulation. Huasheng Zhongtian Machinery Group is a pioneer in the field of garden machinery and plant protection machinery in China, ranking among the top 500 machinery enterprises in China. It is also an internationally leading manufacturer of small gasoline engines. Its "KASEI" brand is renowned worldwide and is a benchmark brand in the industry.
FAQ
How difficult is the operation of a small excavator?
Operating a small excavator requires professional training, but its operation logic is not complicated. We will provide each model with a dedicated operation guidance video to help you quickly master the equipment operation skills.
Is personalized configuration supported?
Support customized services. We can make targeted adjustments to the product's appearance color match
What are the payment methods and delivery times?
The payment method is telegraphic transfer (T/T). The goods will be dispatched within 30 to 40 days after receive deposit.
