1.2 Ton Mini Excavator
Compact and efficient, an expert in all-scenario construction
The CT12BP 1.2-ton mini excavator is specially designed for narrow Spaces and delicate operation scenarios.
This excavator combines powerful performance, comfortable operation and durability, making it an ideal equipment for fields such as building decoration, agricultural horticulture and municipal maintenance.
Application Matrix: Unlocking the possibilities of all scenarios with small devices
Building decoration field
Demolition of interior walls and garbage removal.
Precise excavation of basement pipeline trenches (depth ≤1.8m).
Foundation construction in narrow areas such as elevator shafts and stairwell.
Agricultural horticulture scene
Furrows are dug between the rows of vineyards/orchards for fertilization Soil ploughing and seedbed arrangement in the greenhouse.
Excavation of the root soil ball when transplanting trees.
Municipal maintenance works
The sidewalk tiles are broken and the base layer is leveled.
Dredging of urban drainage ditches and slope trimming.
Micro-terrain transformation of green belts and tree pit excavation.
Industrial auxiliary work
Excavation of pits and trenches for factory equipment foundations.
Partial repair of the damaged area on the warehouse floor.
Auxiliary positioning for hoisting small equipment in the workshop.
| Model | CT12BP | Model | CT12BP |
| Operating weight | 1.2 | G-Tail swing radius (mm) | 806 |
| Bucket capacity | 0.03 | H-Track ground length(mm) | 972 |
| Engine model | YANMAR 3TNV70 | J-Track length (mm) | 1296 |
| Rated power (kw/r/min) | 10.3/2200 | K-Track gauge (mm) | 670（870） |
| Maximum torque （N*m） | 47.6/1600 | L-Track width (mm) | 850-1050 |
| Engine displacement（L） | 0.854 | M-Track shoe width (mm) | 180 |
| Max.flow (L/min) | 17.6 | N-Turntable width (mm) | 850 |
| Working pressure (Mpa) | 17 | O-Max. digging height (mm) | 3018 |
| Fuel tank capacity (L) | 15 | P-Max. dumping height (mm) | 2039 |
| Hydraulic oil tank capacity (L) | 13 | Q-Max. digging depth (mm) | 1809 |
| Travel speed (km/h) | 1.5 | R-Max. vertical wall digging depth (mm) | 1593 |
| Swing speed (r/min) | 10.5 | T-Max. digging reach (mm) | 3439 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3390 |
| Arm digging force | 6 | V-Min. swing radius (mm) | 1591 |
| Bucket digging force (KN) | 10 | X-Distance between center of rotation and tail length (mm) | 806 |
| Average grounding pressure (Kpa) | 33 | Z-Height of counterweight (mm) | 470 |
| A-Overall length (mm) | 3053 | A1-Ground length (in transportion)(mm) | 1560 |
| B-Overall width (mm) | 850/1050 | Arm length (mm) | 890 |
| C-Overall height (to top of boom)(mm) | 1035 | Boom length (mm) | 1500 |
| D-Overall height (to top of cab)(mm) | 2458 | Deflection angle left°/right° | 50°/70° |
| E-Counterweight ground clearance(mm) | 404 | Maximum dozing height/depth (mm) | 195/195 |
| F-Min. ground clearance (mm) | 120 | Dozer size width/height（mm） | 226/850(1050) |
Packaging and transportation of excavators
Relying on a professional loading, unloading and logistics team, we ensure the safe and efficient delivery of excavators to global customers. We offer a wide range of transportation options, including standard container transportation, bulk transportation, and railway transportation.
Company Profile
Shandong CARTER Heavy Industry Co., Ltd. was established in 2004 and is one of the earlier enterprises in China engaged in the production of excavators. The company is affiliated to Huasheng Zhongtian Machinery Group, a large-scale machinery group established in 1951, and has a profound accumulation of over 70 years. Huasheng Zhongtian Machinery Group is a pioneer in the fields of garden machinery and plant protection machinery in China and is listed among the top 500 machinery enterprises in China. It is also an internationally leading manufacturer of small gasoline engines. Its "KASEI" brand enjoys a global reputation and is a benchmark brand in the industry.
As a manufacturer, Carter not only focuses on creating high-quality, high-performance and price-competitive products, but also attaches great importance to achieving timely delivery and round-the-clock after-sales support.
Analysis of Common Problems
What is the price of a small excavator?
The price of the equipment varies due to factors such as configuration parameters and functional modules. You can inform us of your specific requirements through the contact information at the bottom of the page, and we will provide you with a quotation as soon as possible.
How difficult is the operation of a small excavator?
Operating a small excavator requires professional training, but its operation logic is not complicated. We will provide dedicated operation guidance videos for each model to help you quickly master the equipment operation skills.
Is personalized configuration supported?
Support customized services. We can make targeted adjustments to the color matching of the product's appearance.
