1 Ton Mini Excavator
1 Ton mini excavator: Flexible and efficient, small size, big power!
-- Tailor-made for municipal, agricultural, landscaping and other scenarios
✅Compact and flexible, compact excavator is suitable for working in narrow Spaces.
✅Strong power and great digging ability.
✅The operation is simple and easy to get started with.
✅Low fuel consumption and low maintenance cost.
Ultimate flexibility, the king of narrow Spaces
The entire excavator weighs only 980kg and has a chassis width of less than 1 meter, allowing CARTER CT10B mini excavator to easily pass through narrow alleys, greenhouse doors and indoor passageways. Equipped with a 360° full-rotation platform and a compact design with a tail end rotation radius of only 815mm, it can turn flexibly without any blind spots in scenarios such as municipal pipeline maintenance and orchard tree transplanting.
Strong power and efficient breakthrough
CT10B mini excavator is equipped with a YANMAR engine , with a bucket digging force of 7.6KN. It can easily break concrete roads and dig ditches up to 1.52 meters deep. The electric version achieves zero emissions and low noise, making it suitable for indoor operations and environmentally sensitive areas.
| Model | CT10B | Model | CT10B |
| Operating weight | 0.98 | G-Tail swing radius (mm) | 815 |
| Bucket capacity | 0.022 | H-Track ground length(mm) | 900 |
| Engine model | YANMAR 2TNV70 | J-Track length (mm) | 1233 |
| Rated power (kw/r/min) | 7.5/2400 | K-Track gauge (mm) | 660 |
| Maximum torque （N*m） | 31.6/1800 | L-Track width (mm) | 840 |
| Engine displacement（L） | 0.57 | M-Track shoe width (mm) | 180 |
| Max.flow (L/min) | 19.2 | N-Turntable width (mm) | 760 |
| Working pressure (Mpa) | 16 | O-Max. digging height (mm) | 2585 |
| Fuel tank capacity (L) | 10 | P-Max. dumping height (mm) | 1715 |
| Hydraulic oil tank capacity (L) | 9.2 | Q-Max. digging depth (mm) | 1520 |
| Travel speed (km/h) | 2 | R-Max. vertical wall digging depth (mm) | - |
| Swing speed (r/min) | 11.5 | T-Max. digging reach (mm) | 3210 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3125 |
| Arm digging force | 5.8 | V-Min. swing radius (mm) | 1595 |
| Bucket digging force (KN) | 7.6 | X-Distance between center of rotation and tail length (mm) | 815 |
| Average grounding pressure (Kpa) | 29 | Z-Height of counterweight (mm) | 416 |
| A-Overall length (mm) | 2976 | A1-Ground length (in transportion)(mm) | 1755 |
| B-Overall width (mm) | 840/880 | Arm length (mm) | 800 |
| C-Overall height (to top of boom)(mm) | 1110 | Boom length (mm) | 1480 |
| D-Overall height (to top of cab)(mm) | 2225 | Deflection angle left°/right° | 50°/70° |
| E-Counterweight ground clearance(mm) | 370 | Maximum dozing height/depth (mm) | 146/261 |
| F-Min. ground clearance (mm) | 132 | Dozer size width/height（mm） | 215/840 |
Excavator transportation
Our professional loading and logistics team ensures that excavators are transported quickly and safely to customers all over the world. We offer a variety of solutions, such as standard container transportation, bulk cargo transportation and railway transportation.
Why choose us:
As a manufacturer, CARTER is not only committed to providing high quality, high performance, competitive price products, but also provide timely delivery and comprehensive 7/24 hours after-sales service.
Company Profile:
Shandong Caterpillar Heavy Industry Co., Ltd. was established in 2004 and is one of the earliest enterprises in China to produce excavators. Carter is affiliated with Huasheng Zhongtian Machinery Group, a large-scale machinery group established in 1951 with a long history of over 70 years. Huasheng Zhongtian Machinery Group is one of the earliest enterprises in China to produce garden machinery and plant protection machinery. It ranks among the top 500 machinery enterprises in China and is also a world-class manufacturer of small gasoline engines. The KASEI brand has fans all over the world and is a well-known brand in the global industry.
Frequently Asked Questions:
What is the cost of a small excavator?
Excavator prices vary based on features, options and other factors. You can reach us through the contact information below and let us know your needs. We will reply to you as soon as possible.
How to operate a small excavator?
Small excavator operation is not difficult, but need proper training. We will provide teaching videos for each model to help you quickly master the operation of the excavator. Don't worry.
Does it support custom configuration?
Yes, we will customize the color and functional components of the product according to your requirements.
What are the payment method and delivery time?
30 to 40 days after receipt of advance payment by t/t.
Are there any discounts for bulk purchases?
Of course, we will offer appropriate discounts to customers who buy in bulk. You can consult us for specific discounts.
