1.6Ton Mini Excavator
1.6Ton Mini Excavator
CT16--a leading product in the 1.6 - ton mini - excavator category, is designed with the core concept of "Small Size, Big Power". It integrates the world's leading construction machinery technologies to provide intelligent solutions for operations in confined spaces. Equipped with the YANMAR engine , with efficient performance. It is suitable for a variety of scenarios such as landscaping, municipal pipeline laying, and farmland transformation.
1. Ultimate Agility and Unrestricted Mobility
1. Tail - swing Free Design with 360° Zero Tail Swing: The swing radius of the rear of the machine body is only 665mm, enabling seamless operation in narrow areas. It can easily handle complex environments such as urban alleys and indoor construction sites.
2. Extention Chassis: The chassis width can be freely adjusted from 990mm to 1320mm, balancing flexibility and stability to meet different terrain requirements.
2. Versatile Applications and Full - scenario Coverage
1. Quick Attachment Switching: Supports a variety of attachments such as breakers, hydraulic grappler, and augers. With one - key attachment change, it can easily handle multiple tasks such as excavation, breaking, and drilling.
2. Precise Control: The pilot - operated control levers, enable millimeter - level precision control, meeting the requirements of fine - scale construction.
3. Reliability and Easy Maintenance
1. High - strength Structural Design: The frame is welded with thickened steel plates, and key components have passed 2000 - hour fatigue tests. The service life is extended by 30%.
2. Tool - free Maintenance: The semi-open engine compartment and modular component design,simple disassembly and easy maintenance,reducing maintenance costs by 50%.
| Model | CT16-8BL/B4L | Model | CT16-8BL/B4L |
| Operating weight | 1.73 | G-Tail swing radius (mm) | 665 |
| Bucket capacity | 0.04 | H-Track ground length(mm) | 1210 |
| Engine model | YANMAR 3TNV70 YANMAR 3TNV74F | J-Track length (mm) | 1588 |
| Rated power (kw/r/min) | 10.3/2200 11.2/2400 | K-Track gauge (mm) | 760（1090） |
| Maximum torque （N*m） | 47.6/1600 48.5/1800 | L-Track width (mm) | 990（1320） |
| Engine displacement（L） | 0.854 0.993 | M-Track shoe width (mm) | 230 |
| Max.flow (L/min) | 50.6 | N-Turntable width (mm) | 1000 |
| Working pressure (Mpa) | 22.5 | O-Max. digging height (mm) | 3327 |
| Fuel tank capacity (L) | 22 | P-Max. dumping height (mm) | 2323 |
| Hydraulic oil tank capacity (L) | 27 | Q-Max. digging depth (mm) | 2110 |
| Travel speed (km/h) | 2.5/3.9 | R-Max. vertical wall digging depth (mm) | 1600 |
| Swing speed (r/min) | 10 | T-Max. digging reach (mm) | 3947 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3889 |
| Arm digging force | 11.6 | V-Min. swing radius (mm) | 1625 |
| Bucket digging force (KN) | 15.5 | X-Distance between center of rotation and tail length (mm) | 665 |
| Average grounding pressure (Kpa) | 28 | Z-Height of counterweight (mm) | 794 |
| A-Overall length (mm) | 3707 | A1-Ground length (in transportion)(mm) | 2611 |
| B-Overall width (mm) | 990-1320 | Arm length (mm) | 950 |
| C-Overall height (to top of boom)(mm) | 1170 | Boom length (mm) | 1830 |
| D-Overall height (to top of cab)(mm) | 2424 | Deflection angle left°/right° | 56/52 |
| E-Counterweight ground clearance(mm) | 484 | Maximum dozing height/depth (mm) | 240/198 |
| F-Min. ground clearance (mm) | 175 | Dozer size width/height（mm） | 220/966(1320) |
Excavator Package&shipment:
Our professional loading and logistics team ensures that excavators are transported quickly and safely to customers around the world. We provide a variety of solutions such as standard container transportation, bulk transportation, and rail transportation.
Why Choose Us:
As a manufacturer, Carter is committed not only to providing the products with high quality, high performance and competitive price, but also providing timely delivery and comprehensive 7 / 24 after-sales service
Company Profile:
Shandong Carter Heavy Industry Co., Ltd. was established in 2004 and is one of the earliest enterprises in China to produce excavators. Carter belongs to Huasheng Zhongtian Machinery Group, a large-scale machinery group founded in 1951, which has a long history of more than 70 years. Huasheng Zhongtian Machinery Group is one of the earliest manufacturers of garden machinery and plant protection machinery in China, ranks among the top 500 Chinese machinery enterprises, and is also a world-class manufacturer of small gasoline engines. The KASEI brand has fans all over the world and is a well-known brand in the global industry.
FAQ:
1.How Much Does a Mini Excavator Cost?
Excavator prices vary based on features, options,and other factors.You can find us through the contact information below and let us know your needs. We will reply to you as soon as possible.
2.Does it support customized configuration?
Yes, we will customize the color and functional components of the product according to your requirements.
3.What is the payment method and the delivery time?
T/T .30 to 40 days after receiving the advance payment.
