25 Ton Crawler Excavator
25 Ton crawler excavator: Expert in heavy engineering, setting a new standard for efficient operation
Powerful Core: The energy heart for heavy-duty working conditions
Heavy-duty Structure Design: A hardcore guarantee of mine-grade durability
CT260-8A excavator：Solutions for the six golden scenarios
Powerful Core: The energy heart for heavy-duty working conditions
CT260-8A 25ton excavator is equipped with a Cummins 6BTA.A5.9 engine with a rated power of 133kW. It adopts KPM brand hydraulic pumps and valves. The power matching accuracy between the engine and the main pump reaches 98%, and its efficiency is 8% higher than that of traditional models. The maximum torque reaches 708.2/1500N*m, ensuring continuous and stable power output
Heavy-duty Structure Design: A hardcore guarantee of mine-grade durability
CT260-8A crawler excavator is made of high-strength steel with tensile resistance. The weld flaw detection qualification rate of the boom/boom is 100%, and the service life of the key hinge point shaft sleeve is effectively prolonged. Standard equipped with a reinforced X-shaped lower frame, it can still maintain stable walking on a 35° slippery slope. The bucket adopts a bimetallic cladding process, extending the service life of the bucket teeth by 30% and easily handling high-hardness shale layers.
Model | CT260-8A | Model | CT260-8A |
Operating weight | 24.9 | G-Tail swing radius (mm) | 2945 |
Bucket capacity | 1.3 | H-Track ground length(mm) | 3480 |
Engine model | Cummins | J-Track length (mm) | 4256 |
Rated power (kw/r/min) | 133/2000 | K-Track gauge (mm) | 2375 |
Maximum torque （N*m） | 708.2/1500 | L-Track width (mm) | 2915 |
Engine displacement（L） | 5.9 | M-Track shoe width (mm) | 600 |
Max.flow (L/min) | 234*2 | N-Turntable width (mm) | 2736 |
Working pressure (Mpa) | 31.4/34.3 | O-Max. digging height (mm) | 9985 |
Fuel tank capacity (L) | 360 | P-Max. dumping height (mm) | 7170 |
Hydraulic oil tank capacity (L) | 295 | Q-Max. digging depth (mm) | 6525 |
Travel speed (km/h) | 3.3/5.2 | R-Max. vertical wall digging depth (mm) | 6140 |
Swing speed (r/min) | 10.5 | T-Max. digging reach (mm) | 10233 |
Max. climbing degree (%) | 70 | U-Max. digging reach at ground level (mm) | 10225 |
Arm digging force | 148 | V-Min. swing radius (mm) | 3404 |
Bucket digging force (KN) | 159 | X-Distance between center of rotation and tail length (mm) | 2945 |
Average grounding pressure (Kpa) | 45 | Z-Height of counterweight (mm) | 1075 |
A-Overall length (mm) | 10004 | A1-Ground length (in transportion)(mm) | 4850 |
B-Overall width (mm) | 2915 | Arm length (mm) | 3044 |
C-Overall height (to top of boom)(mm) | 3205 | Boom length (mm) | 5850 |
D-Overall height (to top of cab)(mm) | 3007 | Deflection angle left°/right° | - |
E-Counterweight ground clearance(mm) | 1075 | Maximum dozing height/depth (mm) | - |
F-Min. ground clearance (mm) | 470 | Dozer size width/height（mm） | - |
Excavator Package&shipment:
Our professional loading and logistics team ensures that excavators are transported quickly and safely to customers around the world. We provide a variety of solutions such as standard container transportation, bulk transportation, and rail transportation.
Why Choose Us:
As a manufacturer, Carter is committed not only to providing the products with high quality, high performance and competitive price, but also providing timely delivery and comprehensive 7 / 24 after-sales service
Company Profile:
Shandong Carter Heavy Industry Co., Ltd. was established in 2004 and is one of the earliest enterprises in China to produce excavators. Carter belongs to Huasheng Zhongtian Machinery Group, a large-scale machinery group founded in 1951, which has a long history of more than 70 years. Huasheng Zhongtian Machinery Group is one of the earliest manufacturers of garden machinery and plant protection machinery in China, ranks among the top 500 Chinese machinery enterprises, and is also a world-class manufacturer of small gasoline engines. The KASEI brand has fans all over the world and is a well-known brand in the global industry.
FAQ:
1.How Much Does a Mini Excavator Cost?
Excavator prices vary based on features, options,and other factors.You can find us through the contact information below and let us know your needs. We will reply to you as soon as possible.
2.How to operate a mini excavator？
Operating a mini excavator isn’t hard，but it requires proper training.We will provide instructional videos for each model to help you quickly master the operation of the excavator,so don't worry.
3.Does it support customized configuration?
Yes, we will customize the color and functional components of the product according to your requirements.
4.What is the payment method and the delivery time?
T/T .30 to 40 days after receiving the advance payment.
5.Is there a discount for bulk purchasing?
Sure,We will offer appropriate discounts for bulk purchasing.You can consult us for specific discounts.
