3 Ton Excavator
Powerful & Efficient Performance
CARTER CT30B excavator equipped with a YANMAR 3TNV80F diesel engine, this 3-ton excavator delivers robust power while maintaining low fuel consumption . The advanced hydraulic system ensures smooth, precise operations, enabling high digging forces and efficient energy transfer.
Compact Design for Ultimate Maneuverability
With The tailless design and rubber tracks , this compact excavator navigates tight spaces like indoor construction sites, narrow alleyways, and urban landscapes with ease. The zero-tail swing design minimizes overhang, reducing the risk of damage to surrounding structures. Rubber tracks largely reduce the noise caused by friction with the ground during driving.
Multi-Tool Compatibility:
Quick-hitch allows seamless switching between buckets , augers, grapples, and hydraulic hammers .Maximizes machine utilization and reduces downtime.
Operator Comfort & Safety:
Spacious, ergonomic cab with adjustable seats and air conditioning ensures fatigue-free operation.
Low Maintenance & Durability:
Heavy-duty AMCA hydraulic components and reinforced undercarriage withstand harsh working conditions.
Cost-Effective Operation:
Fuel-efficient engine and auto-idle function reduce operating costs.
Long service intervals (500 hours for engine oil) and easy access to maintenance points lower downtime.
Environment friendly
Through Euro V and EPA4 emission standards, emissions are worry-free and environmentally friendly.
| Model | CT30B | Model | CT30B |
| Operating weight | 2.98 | G-Tail swing radius (mm) | 775.0 |
| Bucket capacity | 0.08 | H-Track ground length(mm) | 1600 |
| Engine model | YANMAR 3TNV80F | J-Track length (mm) | 2040.0 |
| Rated power (kw/r/min) | 15.2/2500 | K-Track gauge (mm) | 1250 |
| Maximum torque （N*m） | 63.2/1800 | L-Track width (mm) | 1600.0 |
| Engine displacement（L） | 1.267 | M-Track shoe width (mm) | 300 |
| Max.flow (L/min) | 72 | N-Turntable width (mm) | 1375.0 |
| Working pressure (Mpa) | 24.5 | O-Max. digging height (mm) | 4591 |
| Fuel tank capacity (L) | 35 | P-Max. dumping height (mm) | 3206.0 |
| Hydraulic oil tank capacity (L) | 28 | Q-Max. digging depth (mm) | 3046 |
| Travel speed (km/h) | 2.0/3.2 | R-Max. vertical wall digging depth (mm) | 2723.0 |
| Swing speed (r/min) | 11.5 | T-Max. digging reach (mm) | 5220 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 5121.0 |
| Arm digging force | / | V-Min. swing radius (mm) | 2312 |
| Bucket digging force (KN) | / | X-Distance between center of rotation and tail length (mm) | 775.0 |
| Average grounding pressure (Kpa) | 28.0 | Z-Height of counterweight (mm) | 300.0 |
| A-Overall length (mm) | 4627.0 | A1-Ground length (in transportion)(mm) | 3218 |
| B-Overall width (mm) | 1600 | Arm length (mm) | 1400.0 |
| C-Overall height (to top of boom)(mm) | 1811.0 | Boom length (mm) | 2415 |
| D-Overall height (to top of cab)(mm) | 2560 | Deflection angle left°/right° | 47/74 |
| E-Counterweight ground clearance(mm) | 535.0 | Maximum dozing height/depth (mm) | 362/383 |
| F-Min. ground clearance (mm) | 320 | Dozer size width/height（mm） | 270/1600 |
Packaging and transportation of excavators
Professional loading and logistics team to ensure that excavators can be delivered quickly and safely to customers around the world.Standard container transportation, bulk transportation and railway transportation can choose.
Reasons to choose us
As a manufacturer, Carter is not only committed to providing high-quality, high-performance and competitively priced products, but also attaches great importance to timely delivery.
Company Profile
Shandong CARTER Heavy Industry Co., Ltd. was established in 2004 and is one of the earlier enterprises in China engaged in the production of excavators. The company is affiliated to Huasheng Zhongtian Machinery Group - a large-scale machinery group established in 1951 with a long history of over 70 years. Huasheng Zhongtian Machinery Group is one of the early manufacturers of garden machinery and plant protection machinery in China, ranking among the top 500 machinery enterprises in China. It is also a world-class manufacturer of small gasoline engines. Its "KASEI" brand enjoys a global reputation and is a well-known brand in the industry.
Frequently Asked Questions
What is the price of a small excavator? The price of excavators varies due to factors such as configuration and functional options. You can inform us of your needs through the contact information below and we will reply as soon as possible.
How to operate a small excavator? Operating a small excavator is not complicated, but professional training is required. We will provide instructional videos for each model to help you quickly master the operation methods without any worries.
Does it support custom configuration? Support. We can customize the product color and functional components according to your requirements.
Is there any discount for bulk purchase? Of course, bulk purchases can enjoy corresponding discounts. For specific details of the offers, please feel free to consult us at any time.
