13.5 Ton Crawler Excavator
CT135-9A High-efficiency all-round medium-sized excavator - Outstanding performance, reshaping the new standard of engineering
✅The perfect blend of powerful performance and precise handling
✅Empowered by technology, creating a new comfortable and safe experience
The perfect blend of powerful performance and precise handling
Equipped with a customized and highly efficient power system, CT135-9A crawler excavator is specially designed for complex working conditions, with sufficient power redundancy to ensure stable output even during high-intensity operations. Whether it is the crushing of hard rocks or the rapid excavation of soft soil, it can be easily handled with its strong power. Combined with an advanced hydraulic system, it achieves precise control of the valve core, with sensitive operation response and smooth connection of actions, significantly improving work efficiency and accuracy, truly realizing "instant response, control at will".
Empowered by technology, creating a new comfortable and safe experience
The intelligent cabin adopts ergonomic design. The wide-field cab, combined with a low-noise environment, effectively alleviates fatigue from prolonged work. The integrated touch instrument panel and multi-mode adjustment function enable real-time control of working parameters, and the operation is convenient and intuitive. It is equipped with a standard positive pressure sealing system and high-performance shock absorption devices, which can prevent dust and reduce noise. Even in harsh environments filled with sand and dust, it can still provide drivers with a quiet and comfortable operating space.
| Model | CT135-9A | Model | CT135-9A |
| Operating weight | 13.6 | G-Tail swing radius (mm) | 2380 |
| Bucket capacity | 0.56 | H-Track ground length(mm) | 2930 |
| Engine model | Cummins QSF3.8-C115 | J-Track length (mm) | 3630 |
| Rated power (kw/r/min) | 86/2200 | K-Track gauge (mm) | 1995 |
| Maximum torque （N*m） | 4 3/11 | L-Track width (mm) | 2495 |
| Engine displacement（L） | 3.8 | M-Track shoe width (mm) | 500 |
| Max.flow (L/min) | 126*2 | N-Turntable width (mm) | 2490 |
| Working pressure (Mpa) | 35/38 | O-Max. digging height (mm) | 8600 |
| Fuel tank capacity (L) | 250 | P-Max. dumping height (mm) | 6120 |
| Hydraulic oil tank capacity (L) | 165 | Q-Max. digging depth (mm) | 5455 |
| Travel speed (km/h) | 3.3/5.1 | R-Max. vertical wall digging depth (mm) | 4565 |
| Swing speed (r/min) | 11.5 | T-Max. digging reach (mm) | 8380 |
| Max. climbing degree (%) | 70 | U-Max. digging reach at ground level (mm) | 8255 |
| Arm digging force | 74 | V-Min. swing radius (mm) | 2530 |
| Bucket digging force (KN) | 98 | X-Distance between center of rotation and tail length (mm) | 2380 |
| Average grounding pressure (Kpa) | 38 | Z-Height of counterweight (mm) | 1930 |
| A-Overall length (mm) | 7910 | A1-Ground length (in transportion)(mm) | 4435 |
| B-Overall width (mm) | 2495 | Arm length (mm) | 2500 |
| C-Overall height (to top of boom)(mm) | 2820 | Boom length (mm) | 4600 |
| D-Overall height (to top of cab)(mm) | 2767 | Deflection angle left°/right° | - |
| E-Counterweight ground clearance(mm) | 920 | Maximum dozing height/depth (mm) | - |
| F-Min. ground clearance (mm) | 425 | Dozer size width/height（mm） | - |
Packaging and transportation of excavators
Relying on professional handling and logistics team, ensure the security of the excavator and efficiently delivered to global customers. We offer a wide range of transportation options, including standard container transportation, bulk transportation, and railway transportation.
Enterprise introduction
Shandong CARTER Heavy Industry Co., Ltd. was established in 2004 and is one of the earlier enterprises in China engaged in the production of excavators. The company is affiliated to Huasheng Zhongtian Machinery Group, a large-scale machinery group established in 1951, and has a profound accumulation of over 70 years. Huasheng Zhongtian Machinery Group is a pioneer in the fields of garden machinery and plant protection machinery in China and is listed among the top 500 machinery enterprises in China. It is also an internationally leading manufacturer of small gasoline engines. Its "KASEI" brand enjoys a global reputation and is a benchmark brand in the industry.
FAQ Analysis
What is the price of a small excavator?
The price of the equipment varies due to factors such as configuration parameters and functional modules. You can inform us of your specific requirements through the contact information at the bottom of the page, and we will provide you with a quotation as soon as possible.
How difficult is the operation of a small excavator?
Operating a small excavator requires professional training, but its operation logic is not complicated. We will provide dedicated operation guidance videos for each model to help you quickly master the equipment operation skills.
Whether to support personalized configuration?
Support customized services.We can be targeted to the appearance of the product color adjustment.
