1 T Stand-On Skid Steer
🗝️Key Features：
✅ Compact Design: Only 1.05m wide and 1.3m tall, easily accesses confined spaces
✅ Powerful Engine: 24 hp Yanmar diesel engine, fuel-efficient with high output
✅ Flexible Operation: Stand-on design provides excellent visibility and freedom of movement
✅ Low Ground Pressure: Only 0.312 bar, protects sensitive surfaces
✅ Versatile Hydraulic System: 48 L/min auxiliary flow, supports quick attachment changes
Carter ST1000SL Stand-On Skid Steer — Compact and Agile, Powerful Performance
The Carter MHD925H is a high-performance, compact stand-on skid steer loader designed for tight spaces and demanding working environments. Equipped with a Yanmar efficient diesel engine, it complies with EU Stage Ⅴ / US EPA Tier 4 Final emission standards, combining environmental friendliness with power. It is an ideal choice for landscaping, construction, agriculture, and industrial applications.
⚙️Technical Specifications
Dimensions
| ltem | U.S. Units | Metric Units |
Max Height to Bucket Hinge Pin | 77.2 in | 1.96 m |
Max Operating Height | 106.9 in | 2.7 m |
Machine Height | 51.7 in | 1.3 m |
Length without Attachment | 71.9 in | 1.8 m |
Length with Standard Bucket | 98.2 in | 2.5 m |
Ground Clearance | 5.7 in | 145 mm |
Ground Contact Length | 37.8 in | 960 mm |
Width | 41.3 in | 1050 mm |
Performance
| Item | U.S. Units | Metric Units |
Travel Speed (Fwd/Rev) | 3.3 mph | 5.25 km/h |
Ground Pressure* (200mm tracks) | 4.52 psi | 0.312 bar |
Angle of Departure | 22° | 22° |
Tipping Load | 2094 lb | 950 kg |
Operating Load (35% of tipping) | 734 lb | 333 kg |
Machine Weight (no attachment, full fluids) | 2646 lb | 1200 kg |
Auxiliary Hydraulic Flow | 12.7 gpm | 48 L/min |
Auxiliary Hydraulic Pressure | 2611 psi | 180 bar |
Battery | 12V 60Ah, 475CCA @ -18°C |
Power System
Engine: Yanmar 3TNV80F Diesel Engine
Emission Standard: EU Stage Ⅴ / EPA Tier 4 Final
Cylinders: 3
Displacement: 77.3 cu.in / 1.266 L
Bore × Stroke: 3.2 in × 3.3 in / 80 mm × 84 mm
Rated Power: 24 hp / 17.8 kW
Rated Speed: 3000 rpm
Fluid Capacities
| ltem | U.S. Units | Metric Units |
Fuel Tank | 9 gal | 34 L |
Engine Oil (with filter) | 0.8 gal | 3 L |
Hydraulic System | 11.9 gal | 45 L |
Applications
🏗️ Construction: Indoor/outdoor material handling, cleanup, light excavation
🌳 Landscaping: Digging, transporting, planting, clearing
🏭 Industrial Warehousing: Warehouse organization, loading/unloading, narrow aisle operation
🚜 Agricultural Support: Feed handling, barn cleaning, light field work
Why Choose the Carter ST1000SL?
Ergonomic Design: Stand-on platform offers great visibility and easy control
Economical & Efficient: Yanmar engine ensures low fuel consumption and maintenance costs
Multiple Attachments: Compatible with buckets, milling drums, sweepers, and more
Durable & Reliable: Compact yet robust structure built for tough conditions
