1.2 Ton Crawler Excavator
CARTER CT12B 1.2 Ton crawler hydraulic excavator - small size, big performance
✅High-efficiency power and long-lasting durability
✅Flexible body, adaptable to complex working conditions
✅Humanized design ensures worry-free operation
✅Economical and practical, with high cost performance
✅Environmental Protection and Safety
High-efficiency power and long-lasting durability
CARTER CT12B mini excavator equipped with a YANMAR engine, it has a power output of 10.3kW, excellent heat dissipation performance, and can operate continuously for more than 8 hours without attenuation. The adoption of electronic throttle and automatic fuel return system avoids the risk of fuel depletion and reduces maintenance costs by 30%.
Flexible body, adaptable to complex working conditions
The overall width of the machine is only 850mm, and the chassis can be extended to 1050mm. The rear has a turning radius of 805mm, allowing excavator to easily navigate through scenarios such as greenhouses, orchards, and narrow streets. The maximum digging depth is 1809mm, and the bucket digging force reaches 10kN. This excavator can complete various operations such as trenching, crushing and drilling.
| Model | CT12B4/B | Model | CT12B4/B |
| Operating weight | 1.2 | G-Tail swing radius (mm) | 806 |
| Bucket capacity | 0.03 | H-Track ground length(mm) | 972 |
| Engine model | YANMAR 3TNV74F YANMAR 3TNV70 | J-Track length (mm) | 1296 |
| Rated power (kw/r/min) | 11.2/2400 10.3/2200 | K-Track gauge (mm) | 670（870伸出后） |
| Maximum torque （N*m） | 47.6/1600 48.5/1800 | L-Track width (mm) | 850-1050 |
| Engine displacement（L） | 0.854 0.993 | M-Track shoe width (mm) | 180 |
| Max.flow (L/min) | 17.6/19.2 | N-Turntable width (mm) | 850 |
| Working pressure (Mpa) | 17 | O-Max. digging height (mm) | 3018 |
| Fuel tank capacity (L) | 15 | P-Max. dumping height (mm) | 2039 |
| Hydraulic oil tank capacity (L) | 13 | Q-Max. digging depth (mm) | 1809 |
| Travel speed (km/h) | 1.5 | R-Max. vertical wall digging depth (mm) | 1593 |
| Swing speed (r/min) | 10.5 | T-Max. digging reach (mm) | 3439 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3390 |
| Arm digging force | 6 | V-Min. swing radius (mm) | 1591 |
| Bucket digging force (KN) | 10 | X-Distance between center of rotation and tail length (mm) | 806 |
| Average grounding pressure (Kpa) | 33 | Z-Height of counterweight (mm) | 470 |
| A-Overall length (mm) | 3053 | A1-Ground length (in transportion)(mm) | 1560 |
| B-Overall width (mm) | 850/1050 | Arm length (mm) | 890 |
| C-Overall height (to top of boom)(mm) | 1035 | Boom length (mm) | 1500 |
| D-Overall height (to top of cab)(mm) | 2458 | Deflection angle left°/right° | 50°/70° |
| E-Counterweight ground clearance(mm) | 404 | Maximum dozing height/depth (mm) | 195/195 |
| F-Min. ground clearance (mm) | 120 | Dozer size width/height（mm） | 226/850(1050) |
Excavator packing and transportation:
We have a professional loading and logistics team to ensure that excavators can be quickly and safely delivered to customers around the world. We can provide various transportation solutions such as standard container transportation, bulk transportation and railway transportation.
Choose our reason:
Shandong Carter Heavy Industry Co., LTD., founded in 2004, is one of the early enterprises engaged in the production of excavators in China.As a manufacturer, Carter is not only committed to providing high quality, high performance and price competitive products, but also attaches great importance to timely delivery. Choose Carter. Choose a good partner. The company is affiliated to Huasheng Zhongtian Machinery Group, which is a large-scale machinery group with a long history of over 70 years. Huasheng Zhongtian Machinery Group is one of the enterprises that produce garden machinery and plant protection machinery, and it ranks among the top 500 machinery enterprises in China. His "KASEI" brand enjoys a global reputation and is a well-known brand in the industry.
Frequently Asked Questions
What is the price of a small excavator?
The price of excavators varies due to factors such as configuration and functional options. You can inform us of your needs through the contact information below and we will reply as soon as possible.
How to operate a small excavator?
Operating a small excavator is not complicated, but professional training is required. We will provide instructional videos for each model to help you quickly master the operation methods without any worries.
Does it support custom configuration?
Support. We can customize the product color and functional components according to your requirements.
