6 Ton Crawler Excavator
6 Ton crawler excavator | Highly efficient and durable, precisely controlling every inch of the project
Strong power and high efficiency
Humanized design enhances the operation experience
Durable and reliable, it can adapt to extreme environments
Warranty service
Humanized design enhances the operation experience
Spacious cab: Equipped with floating seats, air conditioning for both heating and cooling, and noise-reducing and sound-insulating materials, it has low noise and is more comfortable for long working hours.
Panoramic view: The front window is sliding and, in combination with LED work warning lights, makes night construction safer.
Durable and reliable, it can adapt to extreme environments
High-strength structural components: The boom/boom is made of tough and durable steel, with a service life of over 8,000 hours. The bucket is thickened with wear-resistant plates, and its impact resistance is enhanced by 40%.
Multiple protections: Standard equipped with underbody guard plates and desert-style air filters, it can operate stably in harsh environments such as sand, dust and mud.
Long maintenance cycle: The oil/filter replacement cycle is extended to 500 hours, reducing maintenance costs by 25%.
| Model | CT60-8B3 | Model | CT60-8B3 |
| Operating weight | 5.82 | G-Tail swing radius (mm) | 1745 |
| Bucket capacity | 0.22 | H-Track ground length(mm) | 2000 |
| Engine model | YANMAR 4TNV94 | J-Track length (mm) | 2665 |
| Rated power (kw/r/min) | 36.2/2100 | K-Track gauge (mm) | 1600 |
| Maximum torque （N*m） | 194.5/1260 | L-Track width (mm) | 2000 |
| Engine displacement（L） | 3.054 | M-Track shoe width (mm) | 400 |
| Max.flow (L/min) | 160 | N-Turntable width (mm) | 1790 |
| Working pressure (Mpa) | 24.5 | O-Max. digging height (mm) | 5889 |
| Fuel tank capacity (L) | 125 | P-Max. dumping height (mm) | 4201 |
| Hydraulic oil tank capacity (L) | 110 | Q-Max. digging depth (mm) | 3812 |
| Travel speed (km/h) | 2.5/4.0 | R-Max. vertical wall digging depth (mm) | 3008 |
| Swing speed (r/min) | 10 | T-Max. digging reach (mm) | 6257 |
| Max. climbing degree (%) | 70 | U-Max. digging reach at ground level (mm) | 6102 |
| Arm digging force | 31 | V-Min. swing radius (mm) | 2585 |
| Bucket digging force (KN) | 45 | X-Distance between center of rotation and tail length (mm) | 1745 |
| Average grounding pressure (Kpa) | 34 | Z-Height of counterweight (mm) | 1062 |
| A-Overall length (mm) | 5943 | A1-Ground length (in transportion)(mm) | 3375 |
| B-Overall width (mm) | 2000 | Arm length (mm) | 1580 |
| C-Overall height (to top of boom)(mm) | 1995 | Boom length (mm) | 3050 |
| D-Overall height (to top of cab)(mm) | 2619 | Deflection angle left°/right° | 53/46 |
| E-Counterweight ground clearance(mm) | 740 | Maximum dozing height/depth (mm) | 335/535 |
| F-Min. ground clearance (mm) | 360 | Dozer size width/height（mm） | 330/1992 |
Excavator packaging and shipment
Relying on a professional loading, unloading and logistics team, we ensure that excavators are delivered to global customers in a safe and efficient manner. We offer diversified transportation options such as standard container transportation, bulk transportation, and railway transportation.
Choose our advantages
As a manufacturer, Carter not only focuses on creating high-quality, high-performance and price-competitive products, but also attaches great importance to achieving prompt delivery and all-weather after-sales support (7× 24-hour service response).
Enterprise Profile
Shandong Caterpillar Heavy Industry Co., Ltd. was established in 2004 and is one of the early enterprises in China to engage in the production of excavators. The company belongs to Huasheng Zhongtian Machinery Group - a large-scale machinery group founded in 1951, with over 70 years of profound accumulation. Huasheng Zhongtian Machinery Group is a pioneer in the field of garden machinery and plant protection machinery in China, ranking among the top 500 machinery enterprises in China. It is also an internationally leading manufacturer of small gasoline engines. Its "KASEI" brand is renowned worldwide and is a benchmark brand in the industry.
Analysis of Common Problems
What is the price of a small excavator?
The price of the equipment varies due to factors such as configuration parameters and functional modules. You can inform us of your specific requirements through the contact information at the bottom of the page, and we will provide you with a quotation as soon as possible.
How difficult is the operation of a small excavator?
Operating a small excavator requires professional training, but its operation logic is not complicated. We will provide each model with a dedicated operation guidance video to help you quickly master the equipment operation skills.
Is personalized configuration supported?
Support customized services. We can make targeted adjustments to the product's appearance color match.
