1.8 T Mini Excavator
1.8-ton excavator - Small size, big power!
Ultimate flexibility
Powerful and efficient
Economic and energy-saving
Stable and reliable
Comfortable and easy to use
Designed specifically for confined Spaces - moving nimbly and reaching everywhere
Ultra-narrow width: Easily pass through narrow doorways, alleys, indoor corridors, and courtyard passageways, solving the pain point of large equipment being unable to enter.
Compact body: Convenient for transportation, it can be easily transferred with a standard small trailer, reducing transportation costs.
Powerful Energy & Efficient Work - Small size unleacks great power
Strong heart: Equipped with a high-performance and low-fuel-consumption Yanmar engine, it provides stable and reliable power output, capable of handling various working conditions.
Advanced hydraulic system: The optimized hydraulic system offers smooth and precise motion control, with excellent coordination of compound actions, significantly enhancing operational efficiency (such as trenching, leveling, loading, etc.).
100%"1139" height="749">
| Model | CT18-9B/B4 | Model | CT18-9B/B4 |
| Operating weight | 1.94 | G-Tail swing radius (mm) | 1072 |
| Bucket capacity | 0.04 | H-Track ground length(mm) | 1210 |
| Engine model | YANMAR 3TNV70 YANMAR 3TNV74F | J-Track length (mm) | 1588 |
| Rated power (kw/r/min) | 10.3/2200 11.2/2400 | K-Track gauge (mm) | 760（1090） |
| Maximum torque （N*m） | 47.6/1600 48.5/1800 | L-Track width (mm) | 990（1320） |
| Engine displacement（L） | 0.854 0.993 | M-Track shoe width (mm) | 230 |
| Max.flow (L/min) | 49.5 | N-Turntable width (mm) | 1000 |
| Working pressure (Mpa) | 21 | O-Max. digging height (mm) | 3327 |
| Fuel tank capacity (L) | 32 | P-Max. dumping height (mm) | 2323 |
| Hydraulic oil tank capacity (L) | 27 | Q-Max. digging depth (mm) | 2110 |
| Travel speed (km/h) | 2.1/4.2 | R-Max. vertical wall digging depth (mm) | 1600 |
| Swing speed (r/min) | 8.5 | T-Max. digging reach (mm) | 3900 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3840 |
| Arm digging force | 8.6 | V-Min. swing radius (mm) | 1575 |
| Bucket digging force (KN) | 13.5 | X-Distance between center of rotation and tail length (mm) | 1072 |
| Average grounding pressure (Kpa) | 28 | Z-Height of counterweight (mm) | 794 |
| A-Overall length (mm) | 3867 | A1-Ground length (in transportion)(mm) | 2535 |
| B-Overall width (mm) | 990-1320 | Arm length (mm) | 950 |
| C-Overall height (to top of boom)(mm) | 1185 | Boom length (mm) | 1830 |
| D-Overall height (to top of cab)(mm) | 2313 | Deflection angle left°/right° | 56/52 |
| E-Counterweight ground clearance(mm) | 484 | Maximum dozing height/depth (mm) | 240/198 |
| F-Min. ground clearance (mm) | 175 | Dozer size width/height（mm） | 220/966(1320) |
Shipment of goods：
We have a professional shipping team. Whether it is containers or bulk cargo, we can ensure the transportation of products well and reduce bumps and knocks.
Company introduction:
CARTER was established in 2004 and is one of theearliest enterprises in China to produce excavators. CARTER is located in Linyi City, Shandong Provincecovering anarea of more than 70,000 squaremeters. As a professional manufacturer with more than 20 years of experience, our company system is perfect, the product is mature, the quality is guaranteed.
FAQ：
Is customer customization supported?
Support. Customers can choose the color and configuration according to their specific circumstances.
Payment method
Telegraphic transfer, 30% advance payment, 70% payment before shipment.
Is there a warranty? How long?
There is a two-year warranty.
