38 T Mining Excavator
🗝️Key Benefits Banner：
✅ ISUZU 212kW Engine
✅ 6915mm Max Dig Depth
✅ 70% Gradeability
✅ 600mm Wide Tracks
CT380-8C Heavy-Duty Mining Excavator | 36.5T Class with 6.9m Digging Depth
Product Description:
Engineered for challenging mining and quarry operations, the CT380-8C crawler excavator delivers exceptional power and durability. Its ISUZU 6HK1XK5C-02 turbocharged engine generates 212kW at 2000rpm, coupled with 1081N·m torque for heavy-duty applications. The dual-pump hydraulic system (300L/min x 2 @ 36MPa) ensures smooth operation in demanding conditions.
🚜Core Specifications :
ISUZU Engine Dominance: 6HK1XK5C-02 Turbo Diesel (212kW/2000rpm | 1081N·m torque)
Unmatched Hydraulic Power: 300L/min x 2 pump flow | 36MPa working pressure
Fuel Efficiency Champion: 590L tank capacity for extended operation
Superior Stability: 65.3kPa grounding pressure on 600mm wide tracks
Mining-Ready Performance: 70% max climb | 10r/min swing speed
Model | CT380-8C | Model | CT380-8C |
Operating weight | 36.5 | G-Tail swing radius (mm) | 3565 |
Bucket capacity | 1.8 | H-Track ground length(mm) | 4150 |
Engine model | ISUZU 6HK1XKSC-02 | J-Track length (mm) | 5080 |
Rated power (kw/r/min) | 212/2000 | K-Track gauge (mm) | 2590 |
Maximum torque （N*m） | 1081/1500 | L-Track width (mm) | 3190 |
Engine displacement（L） | 7.79 | M-Track shoe width (mm) | 600 |
Max.flow (L/min) | 300*2 | N-Turntable width (mm) | 2995 |
Working pressure (Mpa) | 36 | O-Max. digging height (mm) | 10020 |
Fuel tank capacity (L) | 590 | P-Max. dumping height (mm) | 7010 |
Hydraulic oil tank capacity (L) | 350 | Q-Max. digging depth (mm) | 6915 |
Travel speed (km/h) | 3.1/4.8 | R-Max. vertical wall digging depth (mm) | 5170 |
Swing speed (r/min) | 10 | T-Max. digging reach (mm) | 10715 |
Max. climbing degree (%) | 70 | U-Max. digging reach at ground level (mm) | 10515 |
Arm digging force | 200 | V-Min. swing radius (mm) | 4465 |
Bucket digging force (KN) | 246 | X-Distance between center of rotation and tail length (mm) | 3565 |
Average grounding pressure (Kpa) | 65.3 | Z-Height of counterweight (mm) | 2226 |
A-Overall length (mm) | 11386 | A1-Ground length (in transportion)(mm) | 6635 |
B-Overall width (mm) | 3190 | Arm length (mm) | 2763 |
C-Overall height (to top of boom)(mm) | 3410 | Boom length (mm) | 6470 |
D-Overall height (to top of cab)(mm) | 3125 | Deflection angle left°/right° | - |
E-Counterweight ground clearance(mm) | 1220 | Maximum dozing height/depth (mm) | - |
F-Min. ground clearance (mm) | 500 | Dozer size width/height（mm） | - |
Application Scenarios:
🏗️Open-pit mining
🗼Quarry material handling
🚜Large-scale earthworks
🪨Infrastructure development
❓Why Choose CT380-8C?
✅ High-Torque Excavator for rock-breaking & hard soil
✅ Low Ground Pressure Crawler protects terrain
✅ Fuel-Efficient Earthmover with 7.79L displacement
✅ Long-Reach Mining Excavator configuration
✅ Durable Undercarriage: 5,080mm track length
