1 Ton Excavator
1 ton excavator: The ideal choice for efficient engineering
✅Powerful engine, efficient excavation
✅Compact design, flexible operation
✅Multi-functional application to meet diverse needs
✅Low fuel consumption, economical and environmentally friendly
✅Easy operation and comfortable experience
Powerful engine, efficient excavation: Equipped with a high-performance engine, it has strong power and outstanding excavation ability, easily handling various excavation tasks and significantly improving work efficiency. Whether it is hard soil or complex geological conditions, it can demonstrate outstanding excavation performance.
Compact design, flexible operation: The entire machine is compactly designed with a small and flexible body, allowing for free movement and operation in narrow Spaces. With a small turning radius, it can easily adapt to various narrow Spaces, such as urban streets and alleys, indoor construction, and garden landscapes, bringing great convenience to your work.
Multi-functional application to meet diverse needs: It features multiple functions such as excavation, crushing, drilling, and pushing soil. By quickly replacing accessories, it can switch between different operation modes. It meets the diverse demands of various fields such as construction, road maintenance, farmland renovation, and municipal engineering, truly achieving multiple uses with one machine.
Low fuel consumption, economical and environmentally friendly: Advanced energy-saving technologies are adopted, resulting in low engine fuel consumption and effective reduction of operating costs. At the same time, the emissions comply with environmental protection standards, reducing pollution to the environment. It is your best choice for those who value both economic benefits and environmental protection.
Easy operation and comfortable experience: Humanized operation design, light and flexible operation handle, precise control. The spacious and comfortable cockpit, equipped with a good shock absorption system and air conditioning facilities, provides operators with a comfortable working environment and reduces fatigue from long hours of work.
| Model | CT10B | Model | CT10B |
| Operating weight | 0.98 | G-Tail swing radius (mm) | 815 |
| Bucket capacity | 0.022 | H-Track ground length(mm) | 900 |
| Engine model | YANMAR 2TNV70 | J-Track length (mm) | 1233 |
| Rated power (kw/r/min) | 7.5/2400 | K-Track gauge (mm) | 660 |
| Maximum torque （N*m） | 31.6/1800 | L-Track width (mm) | 840 |
| Engine displacement（L） | 0.57 | M-Track shoe width (mm) | 180 |
| Max.flow (L/min) | 19.2 | N-Turntable width (mm) | 760 |
| Working pressure (Mpa) | 16 | O-Max. digging height (mm) | 2585 |
| Fuel tank capacity (L) | 10 | P-Max. dumping height (mm) | 1715 |
| Hydraulic oil tank capacity (L) | 9.2 | Q-Max. digging depth (mm) | 1520 |
| Travel speed (km/h) | 2 | R-Max. vertical wall digging depth (mm) | - |
| Swing speed (r/min) | 11.5 | T-Max. digging reach (mm) | 3210 |
| Max. climbing degree (%) | 58 | U-Max. digging reach at ground level (mm) | 3125 |
| Arm digging force | 5.8 | V-Min. swing radius (mm) | 1595 |
| Bucket digging force (KN) | 7.6 | X-Distance between center of rotation and tail length (mm) | 815 |
| Average grounding pressure (Kpa) | 29 | Z-Height of counterweight (mm) | 416 |
| A-Overall length (mm) | 2976 | A1-Ground length (in transportion)(mm) | 1755 |
| B-Overall width (mm) | 840/880 | Arm length (mm) | 800 |
| C-Overall height (to top of boom)(mm) | 1110 | Boom length (mm) | 1480 |
| D-Overall height (to top of cab)(mm) | 2225 | Deflection angle left°/right° | 50°/70° |
| E-Counterweight ground clearance(mm) | 370 | Maximum dozing height/depth (mm) | 146/261 |
| F-Min. ground clearance (mm) | 132 | Dozer size width/height（mm） | 215/840 |
Mini Excavator Packaging & Shipment
For standard models, we maintain sufficient inventory to ensure immediate delivery upon order confirmation. For customized products, the production and delivery cycle typically ranges from 15 to 30 working days after deposit receipt, subject to adjustments based on specific order configurations and requirements.
