13-Ton Small Excavator
It’s a cost-effective, heavy-duty excavator built for reliability. Whether you need a compact excavator for tight spaces or a powerful machine for large-scale projects, this 13t excavator combines efficiency, durability, and smart technology to elevate your construction performance.
Powerful Performance for Efficient Operations.
Durable & Reliable for Long-Term Use.
Smart Technology for Easy Operation.
Versatile Applications Across Industries.
Powerful Performance for Efficient Operations
Equipped with a high-performance engine, this 13-ton excavator delivers strong power output, easily handling various complex working conditions. Whether it’s excavating hard soil or moving heavy materials, it completes tasks quickly and accurately, significantly boosting construction efficiency. The advanced hydraulic system, perfectly matched with the engine, ensures efficient power transmission, making digging movements smooth and stable with strong digging force—maximizing productivity in every operation.
Durable & Reliable for Long-Term Use
The entire machine structure is meticulously designed with high-strength steel, offering excellent durability and fatigue resistance to withstand long hours of high-intensity work. The optimized chassis system provides superior stability and passability, allowing smooth driving even on rough construction sites. The reliable sl ewing mechanism operates quickly and stably, facilitating flexible adjustment of working directions. An advanced cooling system effectively ensures the engine and hydraulic system run normally in high-temperature environments, maintaining stable equipment performance.
Smart Technology for Easy Operation
Featuring an intelligent control system, operation becomes simpler and more precise. Operators can monitor real-time equipment status, working parameters, and other information through a clear and intuitive display, making it easy to adjust work strategies promptly. Smart sensing technology automatically adjusts engine power and hydraulic system pressure based on digging resistance, achieving a perfect balance between energy efficiency and high performance. The ergonomic joystick design reduces operator fatigue, enhancing comfort—ideal for long-hour operations.
Versatile Applications Across Industries
Compatible with various attachments such as standard buckets, hydraulic breakers, and grapples, this 13t excavator meets the needs of different engineering scenarios. It excels in construction, road building, mining, port loading/unloading, landscaping, and more. With a reasonably designed working radius, it operates flexibly in different spaces, adapting to diverse construction environments.
| Model | CT135-9A | Model | CT135-9A |
| Operating weight | 13.6 | G-Tail swing radius (mm) | 2380 |
| Bucket capacity | 0.56 | H-Track ground length(mm) | 2930 |
| Engine model | Cummins QSF3.8-C115 | J-Track length (mm) | 3630 |
| Rated power (kw/r/min) | 86/2200 | K-Track gauge (mm) | 1995 |
| Maximum torque （N*m） | 4 3/11 | L-Track width (mm) | 2495 |
| Engine displacement（L） | 3.8 | M-Track shoe width (mm) | 500 |
| Max.flow (L/min) | 126*2 | N-Turntable width (mm) | 2490 |
| Working pressure (Mpa) | 35/38 | O-Max. digging height (mm) | 8600 |
| Fuel tank capacity (L) | 250 | P-Max. dumping height (mm) | 6120 |
| Hydraulic oil tank capacity (L) | 165 | Q-Max. digging depth (mm) | 5455 |
| Travel speed (km/h) | 3.3/5.1 | R-Max. vertical wall digging depth (mm) | 4565 |
| Swing speed (r/min) | 11.5 | T-Max. digging reach (mm) | 8380 |
| Max. climbing degree (%) | 70 | U-Max. digging reach at ground level (mm) | 8255 |
| Arm digging force | 74 | V-Min. swing radius (mm) | 2530 |
| Bucket digging force (KN) | 98 | X-Distance between center of rotation and tail length (mm) | 2380 |
| Average grounding pressure (Kpa) | 38 | Z-Height of counterweight (mm) | 1930 |
| A-Overall length (mm) | 7910 | A1-Ground length (in transportion)(mm) | 4435 |
| B-Overall width (mm) | 2495 | Arm length (mm) | 2500 |
| C-Overall height (to top of boom)(mm) | 2820 | Boom length (mm) | 4600 |
| D-Overall height (to top of cab)(mm) | 2767 | Deflection angle left°/right° | - |
| E-Counterweight ground clearance(mm) | 920 | Maximum dozing height/depth (mm) | - |
| F-Min. ground clearance (mm) | 425 | Dozer size width/height（mm） | - |
Why Choose Us？
Firstly, stable and reliable quality and mature technology. Focusing on excavators for 21 years means that we have gone through the tests of different markets around the world - from the high temperature and humidity environment in Southeast Asia, to the strict environmental standards in Europe, and to the heavy load operation needs of mines in Africa. Each of our models (from small 0.6 ton micro excavators to large and medium-sized mining excavators weighing over 49 tons) has undergone at least 3 generations of technological iterations, and the adaptability of core components and the durability of the entire machine have become very mature.
Secondly, the flexibility of the full tonnage product line can truly help you solve the problem of "one-stop procurement". Whether you need small excavators for municipal engineering, large equipment for mining, or even multiple projects with different working conditions at the same time, we can provide matching models. More importantly, equipment of the same brand can save a lot of costs in later maintenance, universal parts, and operator training. For example, there is an African client who is working on both road and farm projects. They have purchased both our 35 ton excavator and 1.6 ton micro excavator. Their maintenance team only needs to be familiar with one system, and their spare parts inventory can be shared, which is much more efficient than collaborating with multiple brands.
